PCIE-Q350 PICMG 1.3 CPU Card
Page 62
The RJ-45 Ethernet connector has two status LEDs, one green and one yellow. The green
LED indicates activity on the port and the yellow LED indicates the port is linked. See
Table 4-17.
STATUS DESCRIPTION STATUS DESCRIPTION
ORANGE 10/100 LAN YELLOW Linked
GREEN GbE LAN
Table 4-17: RJ-45 Ethernet Connector LEDs
4.3.2 USB Connector
CN Label: USB_1 and USB_2
CN Type: USB port
CN Location: See Figure 4-15
CN Pinouts: See Table 4-18
The PCIE-Q350 has four external USB 2.0 ports. The ports connect to both USB 2.0 and
USB 1.1 devices.
PIN NO. DESCRIPTION
1 GND
2 USB_P
4 USB_N
4 USB_5V
Table 4-18: USB Port Pinouts
4.3.3 VGA Connector
CN Label: VGA1
CN Type: 15-pin Female
CN Location: See Figure 4-15
CN Pinouts: See Figure 4-17 and Table 4-19
