PCIE-Q350 PICMG 1.3 CPU Card
Page 98
Manufacturer: Lists the name of the CPU manufacturer
Frequency: Lists the CPU processing speed
FSB Speed: Lists the FSB speed
Cache L1: Lists the CPU L1 cache size
Cache L2: Lists the CPU L2 cache size
Ratio Actual: Clock speed ratio
6.3.2 IDE Configuration
Use the IDE Configuration menu (BIOS Menu 4) to change and/or set the configuration
of the IDE devices installed in the system.
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Exit
IDE Configuration
⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯⎯
SATA#1 Configuration
[Enhanced]
Configure SATA#1 as [IDE]
SATA#2 Configuration [Enhanced]
> Primary IDE Master
: [Not Detected]
> Primary IDE Slave : [Not Detected]
> Secondary IDE Master : [Not Detected]
> Secondary IDE Slave : [Not Detected]
> Third IDE Master : [Not Detected]
> Fourth IDE Master : [Not Detected]
DISABLED: disable the
integrated IDE
controller.
PRIMARY: enables only
the Primary IDE
controller
SECONDARY: enables only
the Secondary IDE
controller.
BOTH: enables both IDE
controllers
Select Screen
↑ ↓ Select
Item
Enter Go to SubScreen
F1 General
Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 4: IDE Configuration
SATA#1 Configuration [Enhanced]
Use the SATA#n BIOS option to enable the nth SATA drive port.
Disabled The nth SATA drive port is disabled
Enhanced D EFAULT The nth SATA drive port is activated
