PCIE-Q350 PICMG 1.3 CPU Card
Page 109
o CPU Temperature
o System Temperature
Fan Speeds: The CPU cooling fan speed is monitored.
o CPU Fan Speed
o System Fan Speed
Voltages: The following system voltages are monitored
o CPU Core
o DDR2 +1.80V
o +3.30V
o +12.0V
o +5VSB
o VBAT
6.3.5 ICP Power Configuration
Use the ICP Power Configuration menu (BIOS Menu 8) to setup ACPI configuration and
power configuration.
BIOS SETUP UTILITY
Main Advanced PCIPNP Boot Security Chipset Exit
> ACPI Configuration
> Power Configuration
Section for Advanced
ACPI Configuration
Select Screen
↑ ↓ Select
Item
Enter Go to SubScreen
F1 General
Help
F10 Save and Exit
ESC Exit
v02.61 ©Copyright 1985-2006, American Megatrends, Inc.
BIOS Menu 8: ICP Power Configuration
6.3.5.1 ACPI Configuration
Use the ACPI Configuration menu (BIOS Menu 9) to select the ACPI state when the
system is suspended.
