PCIE-Q350 PICMG 1.3 CPU Card
Page 14
Processor # CPU Speed FSB Speed Cache Size
E6400 2.13 GHz 1066 MHz 2 MB
E4300 1.80 GHz 800 MHz 2 MB
Table 2-1: Supported Intel® Core™2 Duo (Conroe) Processors
2.3.5 Supported Intel® Celeron® (Conroe L) Processors
Table 2-1 lists the Conroe L core Intel® Celeron® processors supported on the
PCIE-Q350. All the processors in Table 2-1 are 65nm LGA775 processors with the
following features:
Execute Disable Bit
Processor # CPU Speed FSB Speed Cache Size
440 1.86 GHz 533 MHz 1 MB
Table 2-2: Supported Intel® Celeron® Processor
2.4 Intel® Q35 Northbridge Chipset
2.4.1 Intel® Q35 Northbridge Chipset
The Intel® Q35 Northbridge chipset is an advanced Graphics and Memory Controller Hub
(GMCH) that supports a range of Intel® processors including 45nm Wolfdale dual core
and Yorkfield quad core and 65nm Conroe core processors. The Intel® Q35 Northbridge
supports 1333 MHz, 1066 MHz, or 800 MHz FSB and up to 8.0 GB of 667 MHz or 800
MHz DDR2 SDRAM. The Intel® Q35 Northbridge is interfaced to an Intel® ICH9DO
Southbridge chipset through a Direct Media Interface (DMI) communications link.
2.4.2 Intel® Q35 Front Side Bus (FSB) Support
The Intel® Q35 Northbridge supports processors with the following FSB speeds:
800 MHz
1066 MHz
1333 MHz
