PCIE-Q350 PICMG 1.3 CPU Card

Page 81

Figure 5-10: PCIE-Q350 Backplane Installation

Next, secure the CPU card to the chassis. To do this, please refer to the reference

material that came with the chassis.

5.7 Internal Peripheral Device Connections

5.7.1 Peripheral Device Cables

The cables listed in Table 5-3 are shipped with the PCIE-Q350.

Quantity

Type

1

Dual RS-232 cable

1

KB/MS cable with mini DIN

1 PS/2

Y-cable

6

SATA drive cables

3

SATA drive power cables

1 USB

cable

Table 5-3: IEI Provided Cables

Separately purchased optional IEI items that can be installed are listed below:
