PCIE-Q350 PICMG 1.3 CPU Card
Page 80
NOTE:
IEI has a wide range of backplanes available. Please contact your
PCIE-Q350 vendor, reseller or an IEI sales representative at
[email protected] or visit the IEI website (http://www.ieiworld.com.tw)
to find out more about the available chassis.
5.6.2 Backplane Installation
Before the PCIE-Q350 can be installed into the chassis, a backplane must first be installed.
Please refer to the installation instructions that came with the backplane and the chassis
to see how to install the backplane into the chassis.
NOTE:
IEI has a wide range of backplanes available. Please contact your
PCIE-Q350 vendor, reseller or an IEI sales representative at
[email protected] or visit the IEI website (http://www.ieiworld.com.tw)
to find out more about the available chassis.
5.6.3 CPU Card Installation
To install the PCIE-Q350 CPU card onto the backplane, carefully align the CPU card
interface connectors with the corresponding socket on the backplane. See Figure 5-10.
