PCIE-Q350 PICMG 1.3 CPU Card
Page 46
Infrared (IrDA) connector 5-pin header IR1
Keyboard and mouse connector 6-pin wafer MS/KB1
SDVO connector 3-pin header SDVO1
Serial ATA drive connector 7-pin SATA SATA1
Serial ATA drive connector 7-pin SATA SATA2
Serial ATA drive connector 7-pin SATA SATA3
Serial ATA drive connector 7-pin SATA SATA4
Serial ATA drive connector 7-pin SATA SATA5
Serial ATA drive connector 7-pin SATA SATA6
Serial port connector (COM1) 10-pin box header COM1
Serial port connector (COM2) 10-pin box header COM2
TPM connector 20-pin header TPM1
USB connector 8-pin header USB1
USB connector 8-pin header USB2
USB connector 8-pin header USB3
Table 4-1: Peripheral Interface Connectors
4.1.3 External Interface Panel Connectors
Table 4-2 lists the rear panel connectors on the PCIE-Q350. Detailed descriptions of these
connectors can be found in Section 4.3 on page 60.
Connector Type Label
Ethernet connector RJ-45 LAN1
USB connector USB port USB_1
USB connector USB port USB_2
