Operating Characteristics Specifications
CATC IBTrainer InfiniBand Exerciser, August 2002
95
Specifications
This section describes the sspecifications of the IBTrainer Generator for
InfiniBand.
Operating Characteristics
Probing characteristics Connection:
• MicroGigaCN receptacles
• Standard InfiniBand by 4 cables
Transmit and Receive memory size 2048 M x 8-bit DRAM for transmit and 2048 M x 8-bit DRAM for receive.
External Trigger In and Out The IBTrainer Generator for InfiniBand can generate external
trigger_out and can react to incoming trigger_in signals.
The cable should have following characteristics:
Trigger In LVTTL level, low active, internal termination: 50 ohm to
+2.5V, level sensitive
Trigger Out LVTTL level, low active
