Test Description Using the InfiniBand Compliance Test Suite
CATC IBTrainer InfiniBand Exerciser, August 2002
87
LMC Check
TD_10.10.1.1.1
Item Value
Name TD_10.10.1.1.1
Description The ‘DLID’ field in the LRH of a SMP is set to values
covered by the LMC of the DUT.
Topology Simple
Initial link state Active
Assertions v1c07-066#01 v1c07-066#02
Prerequisites SanityCheck
Test procedure The DUT must respond to all LIDs covered by the
LMC value in the PortInfo attribute of the DUT. The
algorithm for the test is as follows:
for (NEWLMC = 0; NEWLMC<8; NEWLMC++) {
1. BASELID=2^NEWLMC
2. in PortInfo of DUT set 'LMC' to NEWLMC
and 'LID' to BASELID
3. LID routed packets with DLID set to valid and in-
valid values are now sent to the DUT:- a response is
expected for
DLID='BASELID-1+2^LMC'- no response is expect-
ed for
DLID='BASELID-1' and
DLID='BASELID+2^LMC'
}
