Using the InfiniBand Compliance Test Suite Test Description
88
CATC IBTrainer InfiniBand Exerciser, August 2002
Number of VLs Supported
v1c07-015
Item Value
Name v1c07-015
Description The ‘OperationalVLs’ field in the PortInfo of the DUT
is set to values covered ‘VLCap’.
Topology Simple
Initial link state Active
Assertions v1c07-015#01
Prerequisites SanityCheck
Test procedure The number of VLs supported by the DUT is request-
ed from the PortInfo attribute 'VLCap':
The PortInfo attribute 'OperationalVLs' of the DUT is
configured with all valid values. It is checked if the
DUT set the VL correctly.
