Getting Started with the IBTrainer Performing a First Test
16
CATC IBTrainer InfiniBand Exerciser, August 2002
For our first test, we use the Sample SMP packet. To set up and send this
packet:
1 Check that this packet is set up so that the IBTrainer queries the
NodeInfo property of the DUT by double-clicking Sample SMP packet.
The SMP Packet: Sample SMP Packet dialog box opens.
This dialog box shows the properties of the selected packet. Following
default values should be set:
– Method is set to 0x01 - Get.
– Attribute ID is set to 0x11 - NodeInfo.
If not set, change these values to the ones above, and click Ok to
accept changes and close the window.
2 Right-click on Sample SMP, and select Transmit to send the packet.
