SierraNet M408 Protocol Analyzer User Manual 209
InFusion Scenarios Teledyne LeCroy
VSAN‐SCSI Command
Status Refer to section “FCP” on page 132.
VSAN‐FCP Task
Management Refer to section “FCP” on page 132.
ARB
VSAN‐ARB Loop
Initialization
Refer to section “ARB” on page 132.
ELS
VSAN‐Extended Link
Service‐Request
Refer to section “ELS Request” on page 132.
VSAN‐Extended Link
Service‐Reply Refer to section “ELS Reply” on page 133.
GS
VSAN‐Generic Link
Service‐Request
Refer to section “GS Patterns” on page 134.
VSAN‐Generic Link
Service‐Reply Refer to section “GS Reply” on page 134.
SW
VSAN‐Switch Internal
Link‐Request
Refer to section “SW Request” on page 136.
VSAN‐Switch Internal
Link‐Reply Refer to section “SW Reply” on page 136.
FICON
VSAN‐FICON (Any Data
Information Block Type)
Refer to section “FICON Patterns” on page 137.
VSAN‐FICON (Data) Refer to section “FICON Patterns” on page 137.
VSAN‐FICON (Command) Refer to section “FICON Patterns” on page 137.
VSAN‐FICON (Status) Refer to section “FICON Patterns” on page 137.
VSAN‐FICON (Control) Refer to section “FICON Patterns” on page 137.
VSAN‐FICON (Command‐
Data) Refer to section “FICON Patterns” on page 137.
VSAN‐FICON (Link‐
Control) Refer to section “FICON Patterns” on page 137.
VSAN‐FCAE‐ASM Refer to section “FICON Patterns” on page 137.
VSAN‐FCAE 1553
VSAN‐FCAE 1553 (Any)
Refer to section “FCAE_ASM” on page 137.
VSAN‐FCAE 1553 (Data) Refer to section “FCAE‐1553” on page 137.
VSAN‐FCAE 1553
(Command) Refer to section “FCAE‐1553” on page 137.
VSAN‐FCAE 1553 (Status) Refer to section “FCAE‐1553” on page 137.
FCVI
VSAN‐FCVI(Any)
Refer to section “FCVI Patterns” on page 137.
Event Description
