numbered cursor pair. Remove a pair by clicking the Remove Cursor button
on the right side of the numbered cursor pair.
Cursors are controlled and interacted with in the following ways:
Selecting a cursor pair button activates the pair.
Pressing the Remove Cursor button for the pair deletes them from
the display.
Double-clicking a cursor pair button automatically zooms and
centers the pair on the Waveform Display Area.
Mark cursor pairs on signals in the waveform display using the following
steps:
1. Select a cursor pair (1-4) from the tools detailed control.
2. Left -click the display to place cursor A (of the pair) at the first
location.
3. Now, right-click the display to place cursor B (of the pair) at the
second location.
Cursors are labeled with the appropriate number and letter for easy
recognition (i.e. 2B).
PLEASE NOTE THE FOLLOWING:
The time difference (and frequency between A and B) is shown
on both the Waveform Display Area and on the Cursors Tool.
When a single cursor (of the pair) is placed, the time and
frequency is shown in real-time based on mouse position until
the second half of the pair is placed (by right-clicking on the
waveform).
Placing the mouse over the active cursor pair shows the
horizontal click-and-drag mouse icon. When this icon appears,
you can horizontally click-and-drag a cursor to a new location.
The display values are updated accordingly.
