IAI America ACON-CG User Manual
Page 25
11
1. Overview
Standard teaching
pendant
RCM-T> External EMG switch Host system Supplied flat cable Input power 24-VDC I/O power supply PC PC software (optional) RS232C type RCA actuator 1.3 System Configuration 1.3.1 Internal Drive-Power Cutoff Relay Type (ACON-C) Caution: Connect one end of the EMG switch to the 24-V output of the input power supply and the other end to the S1 terminal. Also short the S2 and EMG terminals using a jumper wire.
supply
24 VDC
USB type
