133
8. Parameters
If the actuator is moved in the order to positions 1 Ж 2 Ж 3 Ж 4, the actuator will operate differently depending
on whether or not shortcut is selected, as explained below.
When shortcut is not selected
When shortcut is selected
z Absolute unit (No. 83 ETYP)
Parameter No. 83 sets whether or not an optional simple absolute unit is used.
Setting
Not used 0
Used 1
z Current-limiting value at stopping due to missed push-motion (No. 91 PSFC)
The current-limiting value at stopping when the actuator misses the push-motion is defined.
Parameter No.
91
Description
0
Current-limiting value at movement (2.8 to 4 times higher due to the actuator
characteristics)
1 Current-limiting value at push-motion
Point No. 1
Point No. 2
Point No. 3 Point No. 3
Point No. 2 Point No. 4 Point No. 4
Point No. 1
Point No. 1
Point No. 2
Point No. 3 Point No. 3
Point No. 2 Point No. 4 Point No. 4
Point No. 1
