1. Specifications Check
32
1.3.10 Foot (Attached on the Right Side/Left Side)
(Model No.: FT2 (Attached on the Right Side), FT4 (Attached on the Left Side)
This metal part is used for fixing the actuator from the top side using the bolts. For RCA-SRA4R, the
actuator can be attached also to the side.
st+10
121 107
20
55
45
10
RCA-SRA4 R
4 - φ6.6, through
Model code of single product
RCA-FTS-SRA4
