1. Specifications Check
13
1. Specifications Check
1.1 Checking the Product
The standard configuration of this product is comprised of the following parts.
Caution: Check for the enclosed components referring to the component list. If you find any fault or
missing part, contact your local IAI distributor or our company.
1.1.1 Parts
No. Part Name Model Quantity Remarks
1 Actuator Main Body
Refer to “1.1.3 How to Read the
Model Nameplate”, “1.1.4 How to
Read the Model Number”
1
Accessories
2 Motor • Encoder Cable Note1 1
3 Nut Refer to list below
4 First Step Guide 1
5 Instruction Manual (CD/DVD) 1
6 Safety Guide 1
Model No.
Nut A
M26•1.5
Nut B
M35•1.5
Nut C
M8•1.5
Nut A
M30•1.5
Nut B
M40•1.5
Nut C
M10•1.5
RCA-RA3C 1 1 1
RCA-RA4C 1 1 1
RCA-RA3D 1 1 1
RCA-RA4D 1 1 1
RCA-RA3R 2 1
RCA-RA4R 2 1
RCA-RGS3C 1 1
RCA-RGS4C 1 1
RCA-RGS3D 1 1
RCA-RGS4D 1 1
RCA-RGD3C 1 1
RCA-RGD4C 1 1
RCA-RGD3D 1 1
RCA-RGD4D 1 1
RCA-RGD3R 2
RCA-RGD4R 2
Note1 The motor • encoder cables supplied vary depending on the controller used.
[Refer to 1.4, “Motor • Encoder Cables.”]
