Dust and Splash-Proof Type
[RA3C, RA3D, RA4C, RA4D]
RA3D and RA4D are non-brake-equipped types.
[RA3R, RA4R]
Bellows
Right
Left
Motor Side Rod Side
Suction/Exhaust Port
Cylinder Tube
Head Cover
Motor Unit
Cable
Rod Cover
Rod
Rod-Tip Adapter
Brake Unit
Bellows
Right
Left
Suction/Exhaust Port
Cable Motor Unit
Rod
Rod-Tip Adapter Cylinder Tube
Rod Cover
Pulley Case
Head Cover
Motor Side
Rod Side
Brake Unit
