1. Specifications Check
25
3) From the load ratio LF and the acceleration/deceleration time ratio t
od
that were used to figure out the
duty ratio, read the duty ratio.
e.g.) When the load ratio LF = 80% and the acceleration/deceleration time ratio t
od
= 80%, the
reference for the duty is approximately 75%.
1.2.10 Protection class
RCAW-RA3C/RA3D/RA3R/RA4C/RA4D/RA4R 㧩 IP54
Reference for Operation Duty
Acceleration/Deceleration Time Ratio t
od
About
72 %
Less than 50 %
High Accel/Decel Type
High Accel/Decel Type
High Accel/Decel Type
High Accel/Decel Type
