Tubing Material Tubing Size
B.A/P.T Bearing Air (Paint Trigger) Yellow Nylon 6mm OD X 4mm ID
B.A RTN Bearing Air Return Yellow Nylon 4mm OD X 2.7mm ID
BRK Brake Air Orange Nylon 6mm OD X 4mm ID
DL Dump Line Natural PTFE 10mm OD X 8mm ID
F.O Fiber Optic Cable Natural Polyethylene 1/4" OD (jacket)
LV Low Voltage Cable Black N/A N/A
P Paint In Natural PTFE 8mm OD x 6mm ID
PT Paint Trigger Green Nylon 4mm OD X 2.7mm ID
DT Dump Trigger Silver Nylon 4mm OD X 2.7mm ID
SA.I/A.A Inner Shape Air (Atomizer Air) Blue Nylon 8mm OD X 6mm ID
SOL Solvent In Natural PTFE 6mm OD X 4mm ID
SA.O/F.A Outer Shape Air (Fan Air) Gray Nylon 8mm OD X 6mm ID
ST/RP Solvent Trigger Signal Blue Nylon 4mm OD X 2.7mm ID
T.A Turbine Air Green Nylon 10mm OD X 8mm ID
SIGNAL IDENTIFICATION TABLE (METRIC)
Abbr. Description Color
