Install and route the hoses and cable so
that they are NOT exposed to temperatures
in excess of 120 ° F. Ensure that all hose and
cable bends are NOT LESS THAN a 6-inch
(15cm) radius and are not subjected to more
than 360 ° of torsional twist. Failure to comply
with these parameters could cause equipment
malfunctions that might create HAZARDOUS
CONDITIONS!
W A R N I N G
!
>
If a non-explosion proof junction box/terminal
strip is used, it must be located outside the
hazardous area.
W A R N I N G
!
Tubing Material Tubing Size
B.A/P.T Bearing Air (Paint Trigger) Yellow Nylon 1/4" OD X .170" ID
B.A RTN Bearing Air Return Yellow Nylon 5/32" OD X .106" ID
BRK Brake Air Orange Nylon 1/4" OD X .170" ID
DL Dump Line Natural PTFE 5/16" OD X .250" ID
F.O Fiber Optic Cable Natural Polyethylene 1/4" OD (jacket)
LV Low Voltage Cable Black N/A N/A
P Paint In Natural PTFE 3/8" OD X .250" ID
PT Paint Trigger Green Nylon 5/32" OD X .106" ID
DT Dump Trigger Silver Nylon 5/32" OD X .106" ID
SA.I/A.A Inner Shaping Air (Atom, Air) Blue Nylon 5/16" OD X .250" ID
SOL Solvent In Natural Nylon 1/4" OD X .170" ID
SA.O/F.A Outer Shaping (Fan Air) Gray Nylon 5/16" OD X .250" ID
ST/RP Solvent Trigger Signal Blue Nylon 5/32" OD X .106" ID
T.A Turbine Air Green Nylon 3/8" OD X .275" ID
SIGNAL IDENTIFICATION TABLE (ENGLISH)
Abbr. Description Color
>
Do not exceed 100' combined length of the
low voltage cables.
C A U T I O N
!
Tubing Material Tubing Size
B.A/P.T Bearing Air (Paint Trigger) Yellow Nylon 6mm OD X 4mm ID
B.A RTN Bearing Air Return Yellow Nylon 4mm OD X 2.7mm ID
BRK Brake Air Orange Nylon 6mm OD X 4mm ID
DL Dump Line Natural PTFE 10mm OD X 8mm ID
F.O Fiber Optic Cable Natural Polyethylene 1/4" OD (jacket)
LV Low Voltage Cable Black N/A N/A
P Paint In Natural PTFE 8mm OD X 6mm ID
PT Paint Trigger Green Nylon 4mm OD X 2.7mm ID
DT Dump Trigger Silver Nylon 4mm OD X 2.7mm ID
SA.I/A.A Inner Shaping Air (Atom, Air) Blue Nylon 8mm OD X 6mm ID
SOL Solvent In Natural PTFE 6mm OD X 4mm ID
SA.O/F.A Outer Shaping (Fan Air) Gray Nylon 8mm OD X 6mm ID
ST/RP Solvent Trigger Signal Blue Nylon 4mm OD X 2.7mm ID
T.A Turbine Air Green Nylon 10mm OD X 8mm ID
SIGNAL IDENTIFICATION TABLE (METRIC)
Abbr. Description Color
20
Evolver 303 Robotic Atomizers - Installation
Ransburg
AA-07-03.2
