Apply 7969-03 to threads as required.
Install 76566-24C (Ref.) SHCS into Robot Adapter.
Apply 7969-10 to threads as required.
Install tube inserts fully into PTFE tubing before installing tubing into fitting.
PARTS LIST BULLET DEFINITION TABLE - (Figure 31)
1 A11062-00 Assembly, Robot Mounting Plate 1
2 See Table K - "N" Assembly, Cable Low Voltage 1
3 A10891-03 Fitting, 1/4" BSP X 8mm ODT Straight 2
4 A10891-04 Fitting, 1/4" BSP X 10mm ODT Straight 1
5 A10891-02 Fitting, 1/8" BSP X 6mm ODT Straight 2
6 77544-01 Male Connector, 4mm ODT X #10-32 Thd. 4
7 SSF-2052 Set Screw, 3/8" Lg. X #10-24 2
8 See Table L - "Q" Fiber Optic Cable 1
9 A10839-06 Tube, 10mm OD X 8mm ID (Green) 6 Ft.
10 A10893-07 Tube, 8mm OD X 6mm ID (Blue) 6 Ft.
11 A10893-04 Tube, 8mm OD X 6mm ID (Gray) 6 Ft.
12 A10840-09 Tube, 6mm OD X 4mm ID (Orange) See Table J - "M"
13 A10840-08 Tube, 6mm OD X 4mm ID (Yellow) See Table J - "M"
14 77536-06 Tube, 4mm OD X 2.7mm ID (Silver) See Table J - "M"
15 77536-03 Tube, 4mm OD X 2.7mm ID (Green) See Table J - "M"
16 77536-04 Tube, 4mm OD X 2.7mm ID (Blue) See Table J - "M"
17 77536-07 Tube, 4mm OD X 2.7mm ID (Yellow) See Table J - "M"
18 77545-01 Cap, 5/32" OD Tube, Blue Identification 1
19 77545-03 Cap, 5/32" OD Tube, Green Identification 1
20 77545-11 Cap, 5/32" OD Tube, Gray Identification 1
21 77545-12 Cap, 5/32" OD Tube, Yellow Identification 1
22 76566-24C Screw, 1/4-20 X 3/4" Lg. SHCS 6
23 A10841-01 Tubing, 10mm OD X 8mm ID See Table J - "M"
24 A10841-02 Tubing, 8mm OD X 6mm ID, PFA PTFE See Table J - "M"
25 A10841-03 Tubing, 6mm OD X 4mm ID, PFA PTFE See Table J - "M"
26 A11063-00 Insert, Fluid 2
27 A10890-04 Fitting, 6mm ODT X 1/8" BSP 1
28 A10890-02 Fitting, 8mm ODT X 1/4" BSP 1
29 A10891-03 Fitting, 10mm ODT X 1.4" BSP 1
30 A10895-03 Insert, Metric Tube, 6mm 1
31 A10895-01 Insert, Metric Tube, 10mm 1
32 A10895-02 Insert, Metric Tube, 8mm OD 1
33 A11207-06 Cap, 10mm (Green) 1
34 A11208-08 Cap, 8mm (Gray) 1
35 A11208-10 Cap, 8mm (Blue) 1
36 A11209-05 Cap, 6mm (Yellow) 1
37 A11209-03 Cap, 6mm (Orange) 1
38 See Table M - "R" Robot Adapter 1
39 See Table K - "P" Extension, Low Voltage Cable (Not Shown) 1
Item #
A11061-XXXXX TUBING BUNDLE ASSEMBLY (METRIC) -
PARTS LIST (Figure 31)
Part # Description Qty
2
1
4
3
4
2
4
2
3
1
1
2
1
2
2
68
Evolver 303 Robotic Atomizers - Parts Identification
