Ransburg, Evolver 303 robotic atomizers - maintenance – Ransburg Evolver 303 Solvent Applicator A11976-XXX User Manual
Page 40
7
79147-00
Nut, Piston
1
8
7723-06
Piston, U-Cup
1
9
79145-00
Plate, Piston
1
10
79144-00
Shaft, Air Valve
1
11
79001-28
O-Ring, Solvent Proof
1
12
79001-29
O-Ring, Solvent Proof
1
13
79146-00
Seal Carrier, Rear Piston
1
14
79143-00
Bushing, Air Valve
1
15
79001-01
O-Ring, Solvent Proof
3
16
13076-13
O-Ring, PTFE
1
17
79172-00
Carrier, Rear Seal
1
18
79001-06
O-Ring, Solvent Proof
1
19
79137-00
Head, Machining
1
22
79142-00
Screw, #8-32 X .75" Long, SHCS
1
23
79171-00
Spring, Connector
1
24
79141-00
Plug, Connection
1
25
14061-09
Conductive Compressable Contact
1
B
A10400-00
Seal Carrier Tool
1
Item #
79138 EVOLVER APPLICATOR HEAD ASSEMBLY - PARTS LIST (Figure 11)
Part #
Description
Qty
37
Evolver 303 Robotic Atomizers - Maintenance
Ransburg
AA-07-03.2
