Page 35
Item #
SPRAY HEAD ASSEMBLY - PARTS LIST (Figure 10b)
Part #
Description
Qty
1
79148-00
End Cap, Spray Head
1
2
17615-00
Spring, Compression
1
3
9334-00
Spring, Valve Return
1
4
7733-07
Jam Nut
1
5
76199-00
Rear Adjusting Nut
1
6
79151-00
Assembly, Needle Shaft
1
27
RME-38
Return Spring, Piston
1
28
EMF-7
Seal, Washer
1
29 RME-32
Seal
1
30
79001-01
O-Ring, Solvent Proof
1
31
70430-01
Electrode, High Wear
1
32
EMF-195
Nozzle, Fluid Hole
1
33
EMF-192
Locator, Air Cap
1
34
79140-02
Fluid Tip, .055" (1.4mm) Diameter
1
35
79153-65R-1
Air Cap, Pined
1
36
79154-00
Retaining Ring, Tapered
1
>
Ensure that the fan and atomization air
are on and flowing prior to triggering the
fluid. Ensure air before fluid adjustment
is correct. Failure to follow this sequence
will cause spits and defects on the part
being painted.
NOTE
32
Evolver 303 Robotic Atomizers - Maintenance
Ransburg
AA-07-03.2
