Ransburg Evolver 303 Solvent Applicator A11976-XXX - Manual (Page 44)

1 A11214-00 Rod, Support 5
2 79001-14 O-Ring, Solvent Proof 6
3 79001-07 O-Ring, Solvent Proof 10
4 78449-00 Fitting, Fluid 2
5 77531-00 Coil Tube (for Highly Resistive Materials) 1
77517-00 Coil Tube (for Conductive Materials)
78450-00 Coil Tube, (for Highly Conductive Materials)
6 A11201-00 Ring, Quck Disconnect 1
7 77508-00 Bolt, Air 5
8 7683-16C Screw, Break-Away 5
9 A11203-00 Assembly, Break-Away Ring 1
10 A11255-00 Shroud, RMA-303 1
11 A11241-01 Assembly, Valve Manifold 1
12 A11206-01 Assembly, Rear Manifold Plate, RMA-303 (Single Purge) 1
13 76566-24C Screw, #1/4-20 X 3/4" Lg. SHCS 3
14 EMF-203-04 Ferrule, Front 1/4" Tube 2
15 EMF-202-04 Ferrule, Back 1/4" Tube 2
16 79001-06 O-Ring, Solvent Proof 2
17 79001-04 O-Ring, Solvent Proof 1
18 A11983-00 Manifold, Evolver 303, Assembly 1
19 79010-01 Cascade Assembly (HP 404 Type), RMA-303 1
20 A11984-00 #1/4-20 X 3/8" Hex Cap, SC, Black 1
Item #
A11981 SPRAY APPLICATOR ASSEMBLY - PARTS LIST (Figure 13)
Part # Description Qty
41
Evolver 303 Robotic Atomizers - Maintenance
Ransburg
AA-07-03.2
