Apply 7969-03 to threads as required.
Install 76566-24C SHCS into robot adapter (Ref.).
Apply 7969-10 to threads as required.
Install tube inserts fully into PTFE tubing before installing tubing into fitting.
PARTS LIST BULLET DEFINITION TABLE - (Figure 30)
1 A11062-00 Assembly, Robot Mounting Plate 1
2 A10891-03 Fitting, 1/4" BSP X 8mm ODT, Straight 2
3 77544-01 Male Connector, 4mm ODT X #10-32 Thd. 4
4 SSF-2052 Set Screw, 3/8" Lg. X #10-24 2
5 See Table G - "I" Assembly, Cable, Low Voltage 1
6 See Table H - "K" Fiber Optic Cable 1
7 A10893-07 Tube, 8mm OD X 6mm ID (Blue) 6 ft.
8 A10893-04 Tube, 8mm OD X 6mm ID (Gray) 6 ft.
9 77536-06 Tube, 4mm OD X 2.7mm ID (Silver) See Table F - "H"
10 77536-03 Tube, 4mm OD X 2.7MM ID (Green) See Table F - "H"
11 77536-04 Tube, 4mm OD X 2.7mm ID (Blue) See Table F - "H"
12 77545-01 Cap, 5/32" OD Tube, Blue Identification 1
13 77545-03 Cap, 5/32" OD Tube, Green Identification 1
14 77545-11 Cap, 5/32" OD Tube, Gray Identification 1
15 76566-24C Screw, 1/4-20 X 3/4" Lg. SHCS 6
16 A10841-02 Tubing, 8mm OD X 6mm ID See Table F - "H"
17 A11063-00 Insert, Fluid 1
18 A10890-02 Fitting, 8mm ODT X 1/4" BSP 1
19 A10895-02 Insert, Metric Tube, 8mm OD 1
20 A11208-00 Cap, 8mm (Gray) 1
21 A11208-10 Cap, 8mm (Blue) 1
22 See Table I - "L" Robot Adapter 1
23 A12001-00 3/8" Male Connector, 1/4" ISO 1
24 A12002-00 1/4" Male Connector, 1/8" ISO 1
25 -- -- --
26 A10608-01 Tubing, 3/8" OD X .275" ID, Nylon 6 ft.
27 76698-04 Tubing, PFA 450, PTFE See Table F - "H"
28 76698-01 Tubing, PFA 450, PTFE See Table F - "H"
29 A10609-02 Tubing, 1/4" OD X .170" ID, Nylon See Table F - "H"
30 A10609-01 Tubing, 1/4" OD X .170" ID, Nylon See Table F - "H"
31 77947-00 Fitting, Air Modified 1
32 A12003-00 Male Connector, 1/4" T X 1/8" Unifit 2
33 See Table G - "J" Extension, Low Voltage Cable (Not Shown) 1
34 77539-02 Insert, Tube 1
35 77539-04 Insert, Tube 1
36 77545-12 Cap, 5/32" OD Tube, Yellow Identification 1
37 77536-07 Tube, 4mm OD X 27mm ID, Yellow See Table F - "H"
Item #
A12000-XXXXX TUBING BUNDLE ASSEMBLY (ENGLISH) -
PARTS LIST (Figure 30)
Part # Description Qty
4
2
1
2
1
3
2
2
2
4
4
3
2
1
62
Evolver 303 Robotic Atomizers - Parts Identification
Ransburg
AA-07-03.2
