Ransburg Evolver 303 Solvent Applicator A11976-XXX - Manual (Page 11)

Output Voltage: 30-100 kV
Output Range: 0-85 µA
Paint Flow Rate: Variable to 1500 cc/min.
(Depending on viscosity & configuration)
Trigger Response
Time: 134ms Open
318ms Closed
Operating Air Pressures
Atomizing Air: 100 psig (6.9 bar) max.
Fan Air: 100 psig (6.9 bar) max.
Trigger Pilot: 70 psig min./100 psig
(4.8 - 6.9 bar) max.
Dump Pilot: 70 psig min./
100 psig max.
(4.8 - 6.9 bar)
Operating Fluid
Pressure: 200 psig
(13.8 bar) max.
100 psig
(6.9 bar) max.
Regulated (with
on-board regulator)
Robot/Mounting Compatibility:
All hollow wrist robots
Applicator Control Unit:
MicroPak Control Unit - LECU5004-31
Stand-Alone Control Unit - A10406
Operating Temperature
Range: 55°F (12.8°C) - 131°F (55°C)
Weight
Single-Headed:
60° 7.44 lbs. (3.37 Kg)
90° 7.13 lbs. (3.23 Kg)
Dual-Headed:
60° 9.33 lbs. (4.23 Kg)
90° 9.18 lbs. (4.16 Kg)
Manifold:
A11981-XX 5.24 lbs. (2.38 Kg)
(No tubing or cable)
Length
Single-Headed:
60° 15.1 in. (38.4cm)
90° 12.2 in. (36.0cm)
Dual-Headed:
60° 14.2 in. (36.1cm)
90° 11.0 in. (27.9cm)
Tubing Manifolds (English):
A12000-0XXXXXX Air Tubing not
included
A12000-1XXXXXX 15 ft.
A12000-2XXXXXX 30 ft.
Tubing Manifolds (Metric):
A11061-0XXXXXX Air Tubing not
included
A11061-1XXXXXX 4 1/2m (15 ft.)
A11061-2XXXXXX 9m (30 ft.)
SPECIFICATIONS
Atomizing Air
Fan Air
Trigger Air
Dump Pilot
Fluid:
PTFE
Dump:
PTFE
Robot Manifold Tubing Requirements
Tubing Bundle
English
Tubing Bundle
Metric
5/16" OD Nylon
5/16" OD Nylon
1/4" OD Nylon
5/32" OD Nylon
3/8" OD
(Non-Shielded)
1/4" ID
8mm OD Nylon
8mm OD Nylon
6mm OD Nylon
4mm OD Nylon
8mm OD
(Non-Shielded)
8mm ID
Environmental/Physical Electrical Requirements
8
Evolver 303 Robotic Atomizers - Introduction
Ransburg
AA-07-03.2
