Appendix A Technical Specifications
140 PowerSmart+ Power Quality Meter
A.12 Measurement Specifications
Table 21: Measurement Specifications Parameters
Accuracy Parameter Full Scale @ Input
Range
%
Reading
% FS Conditions
Range
Voltage 120VxPT @ 120V
400VxPT @ 690V 0.2 0.02 10% to 120% FS 0 to 1,150,000 V
Starting voltage
1.5-5.0% FS (selectable)
Line current CT 0.2 0.02 For In = 5A
1% to 200% FS
For In = 1A
5% to 200% FS 0 to 50,000 A
Starting current 0.1% FS
Active power 0.36×PT×CT @ 120V
1.2×PT×CT @ 690V 0.3 0.02
|PF| ≥ 0.5 1 -10,000,000 kW to
+10,000,000 kW
Reactive power 0.36×PT×CT@ 120V
1.2×PT×CT @ 690V 0.3 0.04 |PF| ≤ 0.9 1 -10,000,000 kvar to
+10,000,000 kvar
Apparent power 0.36×PT×CT @ 120V
1.2×PT×CT @ 690V 0.3 0.02 |PF| ≥ 0.5 1 0 to 10,000,000 kVA
Power factor 1.000 0.2 |PF| ≥ 0.5,
I ≥ 2% FSI -0.999 to +1.000
Frequency 50 Hz
60 Hz
25 Hz
400 Hz 0.02
0.04 V
L-N
> 25V 15 Hz to 70 Hz
15 Hz to 70 Hz
15 Hz to 70 Hz
320 Hz to 480 Hz
Total Harmonic
Distortion, THD
V (I), %Vf (%If) 999.9 1.5 0.2 THD ≥ 1%,
V ≥ 10% FSV and
V
L-N
> 25V,
I ≥ 10% FSI
0 to 999.9
Total Demand
Distortion, TDD,
% 100 1.5 TDD ≥ 1%,
I ≥ 10% FSI,
V
L-N
> 25V
0 to 100
Active energy
Import & Export Class 0.5S under conditions as per
IEC 62053-22:2003 0 to 999,999,999 kWh
Reactive energy
Import & Export Class 0.5S under conditions as per
IEC 62053-22:2003, |PF| ≤ 0.9 0 to 999,999,999 kvarh
Apparent energy Class 0.5S under conditions as per
IEC 62053-22:2003 0 to 999,999,999 kVAh
PT - external potential transformer ratio
CT - primary current rating of the external current transformer
FSV - voltage full scale
FSI - current full scale
Vf - fundamental voltage
If - fundamental current
NOTES
1. Accuracy is expressed as ± (percentage of reading + percentage of full
scale) ± 1 digit. This does not include inaccuracies introduced by the
user's potential and current transformers. Accuracy calculated at
1second average.
2. Specifications assume: voltage and current waveforms with THD ≤ 5% for
kvar, kVA and PF, and reference operating temperature 20°C - 26°C.
3. Measurement error is typically less than the maximum error indicated.
1 @ 80% to 120% of voltage FS, 1% to 200% of current FS and frequency 50/60 Hz
