Chapter 7 Monitoring Meters Viewing Real-time Min/Max Log
PowerSmart+ Power Quality Meter 117
Saving Data to a File
To save retrieved data to a file for later analysis, click on the Save button
, select an existing database or type the name for a new database,
and then click Save.
To avoid confusion, do not store data files into the Sites directory where
site databases are located.
Printing Data
To check the report, as it will look when printed, select Print Preview
from the File menu.
To print retrieved data, click on the
button on the Power Software
toolbar, select a printer, and then click OK.
Real-time Data Logging
Power Software allows you to store data records to a database
automatically at the time it updates data on the screen.
To setup the real-time logging options:
1. Open the Data Monitor window.
2. Click on the RT Logging On/Off button on the local toolbar,
or select RT Logging Options from the Monitor menu.
3. Select a database, or type the name for a new database and
select a directory where you want to save it.
4. Select the number of tables, and the number of records in each
table you want recorded.
5. Adjust the file update rate for automatic recording. It must be a
multiple of the sampling rate that you defined in the Instrument
Setup dialog.
6. Click Save.
When you run real-time data polling, Power Software automatically saves
retrieved records to a database at the rate you specified.
The RT Logging On/Off button
on the toolbar should be checked all
the time. You can suspend logging by un-checking the button, and then
resume logging by checking it again.
7.2 Viewing Real-time Min/Max Log
To retrieve the real-time Min/Max log data from your meter:
1. Select the device site from the list box on the Power Software
toolbar.
2. Point to RT Min/Max Log on the Monitor menu, and then select
a data set you want to view.
3. Ensure that the On-line button on the Power Software
toolbar is checked.
4. Click on the Poll button .
Power Software supports 9 programmable data sets that you can organize
as you wish. To build your data sets, select MinMax Data Sets from the
Monitor menu or click on the
button on the local toolbar.
See Working with Tables in Chapter 9 for more information on working
with tables.
