Chapter 9 Viewing Files Operations with Files
PowerSmart+ Power Quality Meter 129
Chapter 9 Viewing Files
9.1 Operations with Files
Files you read from the meters are stored in one or in a number of tables
in the meter database. Sections of multi-section files like energy load
profiles are stored in multiple tables – each file section in a separate
database table.
Opening a Database Table
To open a database table:
1. Click on the Open button
on the Power Software toolbar, or
select Open... from the File menu.
2. Select Access Database (*.mdb) in the Files of type box;
select a directory where your files are located, and point to the
file you wish to open.
3. Select a desired table on the right pane, and then click Open, or
double click on the table name.
Names of the last 16 files you opened are stored in the File menu, so you
can select them directly from the menu.
Saving Data to a File
To save data from the open database table to a file:
1. Click on the Save button
, and select a directory where you
want your file to be stored.
2. Select a database or type the name for a new database.
3. Click Save.
To avoid confusion, do not store data files into the Sites directory where
site databases are located.
9.2 Viewing Options
Customizing Views
Changing Date Order
To change the way Power Software displays the date:
1. Select Options from the Tools menu and click on the
Preferences tab.
2. Select the preferred date order.
3. Click OK.
Selecting Timestamp Format
The timestamp is normally recorded and displayed on the screen at a 1-
ms resolution. If you have an application that does not support this
format, you may instruct Power Software to drop milliseconds.
To change the way Power Software records and displays the timestamp:
1. Select Options from the Tools menu and click on the
Preferences tab.
2. Select the preferred timestamp format.
