Chapter 8 Retrieving and Storing Files Uploading Files on Demand
PowerSmart+ Power Quality Meter 123
Chapter 8 Retrieving and Storing Files
Power Software allows you to retrieve recorded events and data from your
meters and to save them to files on your PC in the Microsoft Access
database format.
Historical data can be uploaded on demand any time you need it, or
periodically
through the Upload Scheduler that retrieves data
automatically on a predefined schedule, for example, daily, weekly or
monthly.
If you do not change the destination database location, new data is added
to the same database so you can store long-term data profiles in one
database regardless of the upload schedule you selected.
8.1 Uploading Files on Demand
To retrieve the log files from your meter:
1. Ensure that the On-line button
on the Power Software toolbar
is checked.
2. Select a device site from the list box on the Power Software toolbar.
3. Select Upload Logs from the Logs menu.
4. Select a database, or type the name for a new database, and select
a directory where you want to save it.
5. Click on the Select Logs button and check boxes for logs you want
to be retrieved from the meter.
6. If you wish to retrieve data starting with a known date, check the
“From” box and select the start date for retrieving data.
7. If you wish to retrieve data recorded before a known date, check
the “To” box and select the last date for retrieving data.
8. Click OK.
