Settings and Calibration Model 7500ZA
Teledyne Analytical Instruments 52
Caution: When an auto calibration starts, the measurement
screen appears automatically.
Any operation other than “Stop Auto Calibration”
(see Item 6.4.2) is not permitted during auto
calibration. “Stop Auto Calibration” cannot be
performed with the key lock to ON.
To force a cancel of the auto calibration, set the
key lock to OFF and then execute “Stop Auto
Calibration”.
Turn power OFF and then ON again at the time set
as the next start time in auto calibration, and then
repeat it in the set cycle.
Remote Start
Whether the auto calibration is set at ON or OFF, an auto
calibration is always available via a remote start input.
6.4.2 Forced Run/Stop Of Auto Calibration
Auto calibration can be performed just once or forcibly stopped
while the calibration is in process
6.4.2.1 E XECUTION OF AUTO
CALIBRATION ( ONLY ONCE )
1. In the “Set Auto Cal
screen, move the cursor
to “Auto Cal Run” using
the UP or DOWN key,
then press ENT.
2. “Run” is highlighted,
displaying a message to
