Teledyne 7500ZA - Infrared Gas Analyzer User Manual
Page 35
NDIR Gas Analyzer
Instalation
Teledyne
Analytical
Instruments
19
(4) Contact input/output (DIO): digital input/output connector
(DIO 1 to 3)
Contact input signal : Voltage is applied from the external 12 to 24 V
DC, max 15mA.
Photo-coupler isolation (from each DI and
ground)
Contact capacity :
C contact relay output 24V/1A AC/DC
resistive load
