Specifications Model 7500ZA
Teledyne Analytical Instruments 92
Power Supply: Voltage rating: 100V to 240V AC
Allowable range: 85V to 264V AC
Frequency: 50Hz/60Hz
Power consumption: 100VA max.
Operating Conditions:
Ambient temperature: -5˚C to 45˚C
(40˚C max. when 2
optical system at
200V AC power
source)
Ambient humidity: 90% RH max.,
non-condensing
Storage Conditions:
Ambient temperature: -20˚C to 60˚C
Ambient humidity: 100% RH max.,
non-condensing
Dimensions (H × W × D): 133 x 483 x 382mm
Mass: Approx. 9 kg
Enclosure: S teel casing, for indoor use
Material for Wetted Parts:
Gas inlet/outlet; SUS304
Sample cell; SUS304,chloroprene rubber
Infrared-ray transmitting window: CaF
2
Internal piping: Toaron, Teflon,
Polypropylene
Paramagnetic O
2
sensor cell : SUS316
Fuel cell O
2
sensor cell: ABS resin
Gas inlet/outlet: Rc1/4 or NPT 1/4 internal thread
Purge gas flow rate: 1L/min ( when required)
Life time of Fuel Cell O
2
Sensor: 2 years
