Liquid Controls DMS Delivery - Manual (Page 36)

36
Utilities
*Auxiliary Setup
The Auxiliary Setup screen is used to define actions for
the auxiliary outputs during the delivery. It also has an
option to change the setting of the No-Flow Timer.
*PRODUCT
Opens a list box window of available product codes.
*AUX1
Open a list box window with the options:
Monitor Flow Rate: This option activates auxiliary 1 at
the beginning of each delivery. If the flow rate during
the delivery meets or exceeds 40 gpm, auxiliary 1
will deactivate. This option is typically used to monitor
the amount of restriction in a strainer basket or filter
in order to discover clogs.
Off: This option deactivates auxiliary 1.
On: This option activates auxiliary 1. It remains activated
even when a delivery is not taking place.
On During Delivery: This option activates the auxiliary
output only when the system is in an active delivery,
and prints header line 11 on the ticket.
*AUX2
Open a list box window with the options:
Flow Direction: This option indicates the flow direction
through the flow meter.
Off, On, On During Delivery: All these are defined in
Aux1 above. If set to On During Delivery, header
line 12 will print on the ticket.
NO-FLOW TIMER
Opens a field box window where you can enter a value
between 0 and 3600 seconds. If there is no flow through
the meter over a set amount of time, the timer will end
the delivery. If this value is set to 0, then each delivery
ticket will contain the text “MULTIPLE DELIVERIES AT
ONE SITE”.
* Not available as of 11-01-2006
Next (F1) scrolls forward through product codes
Prev (F2) scrolls backwards through product codes
Status (F3) advances to the Machine Status screen (pg 32)
Back (F4) returns to customer account screen (pgs 15-24)
