34
operatIon -
prInterS & databaSe management
prInterS
FlightConnect Fueling Systems typically include an Epson Roll Printer; however, Epson Slip Printers can be used
as well. Slip printers can prevent fuelers from starting a fueling if a ticket is not engaged in the printer. Keys to the
indicator lights and button functions are shown below.
SlIp prInter buttonS and IndIcator lIghtS
powER light - light indicates power is on
RELEaSE light- light indicates ticket can be removed
papER out light- light indicates no paper in printer
foRwaRD button - moves paper forward
REVERSE button- moves paper backward
RELEaSE button- release ticket for removal
roll prInter buttonS and IndIcator lIghtS
ERRoR light- light indicates printer unable to print (see printer
manual)
powER light - light indicates power is on
papER out light- light indicates no paper in printer
fEED button - moves paper forward
database management
The Database Management screen provides commands for sending and receiving data from the office.
The
Send Transactions to Office command sends fueling data from the LCR 600 to the office. After the LCR 600
records the fueling data, an indicator arrow will appear on the Fueler Menu bar until the transaction data is sent to
the office.
To send updates to the office:
1. From the Fueler Menu, move the highlighted bar to
Database Management and press the EntEr button.
2. Move the pointer  to Send Transactions to
Office, press the EntEr button, move the highlighted
bar to Yes, and press the EntEr button. Scheduled Fueling
Manual Fueling
Fueler Logoff
Database Management
Configuration Menu
G a l l o n s
F u e l e r M e n u
Indicator Arrow
Transaction records
available for office
DBManager & ACRead must be
running on the office computer to send
and retrieve data from the LCR 600.
DBManager & aCRead
In the System Definitions tab of FlightConnect Edit, data transmissions between the LCR 600 and the office
can be set to transmit automatically at LCR 600 power on, fueler logon, fueler logoff, and after fuelings.
automatic Data transmission
This message is displayed when the LCR 600 is attempting to
send data to the office. It is not a confirmation that the data has
been sent. If the indicator arrow still appears in the Fueler Menu,
there are transactions that haven’t been sent to the office.
Processing transaction records...
The LCR 600 will not begin a fueling without a ticket
engaged in the slip printer.
To engage a ticket in an Epson Slip Printer:
1. Press RELEASE on the printer. Insert a blank fueling
ticket.
2. Press FORWARD on the printer to engage the ticket.
