Liquid Controls FlightConnect 600 - Manual (Page 31)

31
G a l l o n s
N e w F u e l i n g
Transaction:
Customer:
Tail #:
Fuel Location:
Flight #:
Aircraft Type:
Fuel
Big Air
N7987D
Gate 2
5563
B737
To complete a Manual Fueling:
1. In the Fueler Menu, Move the highlighted bar to Manual
Fueling and press the EntEr button.
2. Enter the correct values into the series of fueling screens
until the New Fueling screen appears.
3. To edit a fueling data fields in the New Fueling screen,
move the highlighted bar to a data field, press the EntEr
button, enter the new value, and press EntEr to accept.
4. Turn the LCR 600 selector switch to RUN.
5. Take the nozzle to the fueling point and fuel the tank.
6. Turn the LCR 600 selector switch to PRINT to print a
record of the fueling.
manual fuelIng
Manual fuelings allow the fueler to define the data fields
before the fueling. When a manual fueling is selected
in the Fueler Menu, FlightConnect LCR 600 will display
a series of data field screens in which the fueler can
enter specific details of the next fueling. Which data field
screens and the number of screens that appear in the
series is configured in FlightConnect Edit on the office
computer.
To exit a fueling (before turning the red selector switch
to run, opening the valve and delivering fuel onto the
plane), press ESC until the Fueler menu appears
Exit a fueling
G a l l o n s
D i s p a t c h R e c o r d s
Fuel
Customer:
Tail #/Flight #
Fuel Location:
Aircraft Type:
Fuel Type/Additive
Dispatched Volume
ENTER=Accept R=Reject ESC=Menu 
10/21/15 13:05:58
Big Air
N7987D/5563
Gate 2
B747
Jet A/No
500
Indicator Arrows
Additional records available
To complete a Scheduled Fueling:
1. Move the highlighted bar to Scheduled Fueling and
press the EntEr button.
2. If more than one dispatch record is available, use the
 and  buttons to page through the dispatch records.
Arrows in the bottom right corner of the screen indicate additional
dispatch records are available.
3. To accept the dispatch record displayed on the screen,
press the EntEr button to open the New Fueling screen.
To reject and erase the dispatch record displayed on
the screen, press the
P Q
R
6
PQr6 button then confirm the
rejection in the list box.
4. To edit a fueling data fields in the New Fueling screen,
move the highlighted bar to a data field, press the EntEr
button, enter the new value, and press EntEr to accept.
5. Turn the LCR 600 selector switch to RUN.
6. Take the nozzle to the fueling point and fuel the tank.
7. Turn the LCR 600 selector switch to PRINT to print a
record of the fueling.
Scheduled fuelIng
Scheduled fuelings are fueling assignments (or Dispatch
Records) defined in the office (by FlightConnect
Dispatch) and wirelessly sent to the LCR 600.
Typically, dispatched fueling assignment are received
automatically when the LCR 600 communicates with
the office server during power on, logon, logoff, after
fuelings, and/or periodically at a set time span. These
automatic communications are setup in FlightConnect
Edit. Dispatch Records can also be retrieved by a fueler
manually by selecting Retrieve database Updates
from Office in the Database Management screen. See
Database Management on page 35 for instructions.
The fueler can scroll through numerous dispatch records
on the LCR 600 and select the correct record before
fueling. The fueler also has the option of editing data
fields in the dispatch record before fueling.
Scheduled & manual fuelIng
- operatIon
Data fields can be modified during a fueling. See page 33.
in-fueling Data field Edits
Scheduled and manual fueling (cont’d)
