Setup -
SyStem Setup
SyStem Setup 1
Meter ID:
(tB)
c
The identification number of the flowmeter the LCR 600 is mounted
on. If the LCR 600 is installed in a multiple-meter system, it is
important this number be unique. The number is printed on the
calibration/diagnostic ticket. LC recommends entering the flowmeter’s
serial number to ensure identification.
Unit of Measure:
(LB)
c
The unit of flow measurement.
Gallons • Litres • Cubic M • Lbs (pounds) • Kgs •
Barrels • Other
Decimal Digit:
(LB)
c
flightconnect
The decimal place of volume measurements shown on the display and printed tickets.
Whole is the preferred
FlightConnect setting.
Hundredths • Tenths • Whole
Residual Processing:
(LB)
c
The treatment of excess decimal places when displaying and printing volume measurements.
Round is the preferred
FlightConnect setting.
Round according to one half of the least significant digit
Truncate disregards the excess digits
Flow Rate Base:
(LB)
c
The time unit of the measured flow rate.
Per Minute is the preferred FlightConnect setting.
Per Second • Per Minute • Per Hour
Flow direction:
(LB)
c
The direction of flow through the flowmeter. If the LCR 600 is counting in reverse (decreasing numbers), select the
opposite Flow Direction.
<− • −>
Printer:
(LB)
c
The type of printer connected to the LCR 600.
ePSoN NewFontB epSON 200 Roll and epSON 220 Roll
ePSoN NewFontA epSON TM-T88iii
ePSoN oldFontA epSON 290 Slip and epSON 295 Slip
ePSoN oldFontB epSON 300 Roll
OKIDATA ML184T OKIDATA ML184T
BLASTeR Cognitive Solutions Thermal printer.
Ticket Required:
(LB)
c
flightconnect
Determines if the printer is required to be online and ready to print in order to start a fueling. Most Weights &
Measures governed truck applications require a ticket.
Yes is the preferred FlightConnect setting.
Yes fuelings disabled unless a ticket is in the printer, the previous fueling ticket is completed, and the printer is operational.
Skip fuelings enabled without printer. Tickets will not print even if the printer is online and has paper.
No fuelings enabled without printer. Tickets will print if the printer is online and has paper.
dP Shutdown Value:
(tB)
c
flightconnect
The differential pressure amount that will shut down an active fueling. This feature pertains to flowmeter systems
with a differential pressure transducer and requires a shutdown device. If the value is set to 0, the feature is disabled.
0-59.9 range.
Next/Previous Screen
S Y S T E M S E T U P
1
Meter ID:
Unit of Measure:
Decimal Digits:
Residual:
Flow Rate Base:
Flow Direction:
Printer:
Ticket Required?
dP Shutdown Value:
LCR Node Address:
Delivery Screen:
A101
GALLONS
TENTHS
ROUND
PER MINUTE
->
EPSON OldFontA
YES
25.0
250
Aviation
l - locked
u - unlocked
c - Weights & measures calibration
p - Stop/pause
f - factory
Security clearance
