21
SyStem Setup
- Setup
LCR Node Address: (tB) c - u
Designates the LCR 600 as a single or dual node unit. If the fueling vehicle has one LCR 600 installed, this field
should be set to 1. If the fueling vehicle has two LCR 600s installed, one LCR 600 should be designated as Node
1 and the other LCR 600 should be designated as node 2 in this field. The value of this field will be reflected in the
invoice number generated by FlightConnect.
delivery Screen: (tB) c flightconnect
The format of the active delivery screen, four predefined. Aviation is the preferred FlightConnect setting.
User Defined • Detailed Pump & Print • Volume and Preset • Aviation • Detailed POS
SyStem Setup 2
Temperature:
(tB) c
The current temperature reading of the RTD temperature probe. To
calibrate, simply enter the Weights & Measures thermometer reading. If the
LCR 600 does not have an ETVC Kit, this field will read “--”.
Temperature offset: (tB) c
The difference between the official Weights & Measures reading and the
LCR 600 RTD reading. The offset is automatically calculated if an entry is
made in the Temperature: field. ±0.3 °C ( ±0.54 °F) range.
Temperature Unit/Measure: (LB) c
The unit of temperature measured, displayed, and printed.
Deg. C • Deg. F
RTd Slope: f
Factory calibration setting only.
RTd offset: f
Factory calibration setting only.
DBM Node Address: (tB) c This field is for configuring LCR 600 data transmission
The address of DBManager, Liquid Controls’ database management office software. This node aligns wireless
communication between the office and fueling vehicle. Nearly all installations will use the default setting of 255.
File Server Parameters
Node Address:
(tB) c This field is for configuring LCR 600 data transmission
A unique node address for the LCR 600, used by DBManager (Liquid Controls’ database management software for
the office computer) to identify the LCR 600 unit in the wireless network. This field value must be unique among LCR
600 units in the wireless network and have a matching Node # in the Registered Files Server Nodes of the DBManager.
File Server Port: (LB) c This field is for configuring LCR 600 data transmission
The LCR 600 CPU port designated for serial communication to a wireless device. J3 is the default and the standard
LCR 600 communication port for data transfer output.
J1 • J2 • J3
Baud Rate: (LB) c This field is for configuring LCR 600 data transmission
The communication speed. This value should match the wireless device connected to the LCR 600. 57600 is the
standard communication speed, but check your wireless device specifications to ensure the proper selection.
115200 • 57600 • 19200 • 4800 • 2400
Retries: (tB) c flightconnect This field is for configuring LCR 600 data transmission
After a failed initial attempt, the number of attempts the LCR 600 will try to make a serial connection with the wireless
communication network before timing out. 1 is the preferred FlightConnect setting.
Timeout: (tB) c This field is for configuring LCR 600 data transmission
The amount of time, in milliseconds, the LCR 600 will wait for a response, once a serial signal is sent to a wireless
network, before timing out.
TX enable: (LB) c This field is for configuring LCR 600 data transmission
The setting for the serial signal transmit and receive handshake technique to the wireless device. None is the default
setting.
None • !RTS • RTS • !DTR • DTR • !RTS!DTR
Next/Previous Screen
S Y S T E M S E T U P
Temperature:
Temperature Offset:
Temperature Unit/Measure:
RTD Slope:
RTD Offset:
74.73
0.00
DEG. F
0.0155
-124.6
DBM Node Address:
File Server Parameters
Node Address:
File Server Port:
Baud Rate:
Retries:
Timeout:
Tx Enable:
255
1
J3
19200
1
6000
NONE
2
tB - text Box
LB - List Box
field type
