19
Print Gross and Parameter? (LB) c flightconnect
Determines if the gross volume and compensation parameter is printed on the ticket. Applies to temperature
compensated products only. No is the preferred FlightConnect setting.
Volume Corrected Message? (LB) c flightconnect
Determines if the message noting that the fueling volume has been corrected to a base temperature is printed on
the ticket, for example “Gallons corrected to 60.0ºF”. No is the preferred FlightConnect setting, unless temperature
compensation is active.
Pulse Output Edge: (LB) c
Determines the signal of the calibrated pulse output waveform. Some external components function on rising pulse
edges, others on falling pulse edges. Refer to the technical manual of the external component receiving the pulse to
determine requirements.
Falling • Rising
Pulse output Freq: (tB) c
Determines the frequency of the pulse output per unit of measure sent by the Auxiliary Output 3 on terminal 42 of
the J12 terminal block. Common components that are connected to Auxiliary Output 3 include external counters
and injection systems. This field is a multiplier of the calibrated pulse output. If 10 is the field value, the Auxiliary
Output 3 will be 10 pulses (10 x 1) per the least significant digit of the calibrated pulse output. If .1 is the field value,
the Auxiliary Output 3 will be 1 pulses (.1 x 1) per every 10 least significant digits of the calibrated pulse output. The
default value is 1. At the default value, the output will be 1 pulse per each least significant digit counted on the display.
general Setup 2
No-Flow Timer:
(tB) u - l flightconnect
The amount of time until the LCR 600 ends a fueling and prints a ticket
after it senses that no product is flowing through the meter. The time can
be set from 0 to 3600 seconds. 0 is the preferred FlightConnect setting.
A 0 setting will keep the transaction active until a print or end of fueling
command is generated.
Ticket Header Text: (tB) c - u (Lines 11 and 12 c only)
Supplies 12 lines where you can enter text for the ticket header. Every
fueling ticket printed by the LCR 600 will print this text at the top of every
ticket. FlightConnect ticket headers are created in FlightConnect Edit. The
preferred FlightConnect setting is to leave these fields blank
general Setup
- Setup
G E N E R A L S E T U P
Next/Previous Screen
2
No-Flow Timer
Ticket Header Text
1:
2:
3:
4:
5:
6:
7:
8:
9:
10:
11:
12:
0
tB - text Box
LB - List Box
field type
