calIbratIon Setup
- Setup
multi-point calibration proving - continued
Next/Previous Screen
GALLONS
APPLIED
50.12
Flow Rate
88.00
11.00
38.00
22.00
30.00
63.00
75.00
0.00
0.00
0.00
Percent Error
-0.030
-0.108
-0.138
-0.171
-0.149
-0.084
-0.055
0.000
0.000
0.000
Calibration #: 1
Linearization Mode:
Linearization Prover Qty:
BEGIN CALIBRATION DELIVERY
Point #
1:
2:
3:
4:
5:
6:
7:
8:
9:
10:
C A L I B R A T I O N S E T U P 3
LCR-600: 60011
Adjacent linearization points out of
0.25% range.
The LCR 600 will not allow you to enter the Applied
setting of the Linearization Mode: until all adjacent
calibration points are within 0.25% of each other.
To prove a flowmeter system to a product with
multi-point calibration (cont’d):
10. Repeat steps 4 through 10 using a new flow rate for the
next Point #: until all the points between the lowest
flow rate and the maximum flow rate are within 0.25% of
each other.
11. Navigate to Calibration Setup 1. Move the pointer  to
Linearization Mode: and select Applied.
The linearization points on Calibration
Setup 3 will automatically sort by flow rate
after the Applied setting is selected.
compensation types and parameters
product vcf type
parameter
Coefficient
range
ºcelsius/
ºfahrenheit tbase tmin
thold tmax
General Linear Linear 0 to 0.003 ºC 15 -90 N/A +100
General Linear Linear 0 to 0.005 ºF 60 -130 N/A +212
LPG
USA
API Table 24 Specific Gravity 0.5 to 0.550 ºF 60 -50 -50 +140
LPG
Europe & Canada
API Table 54
Density
kg/L
0.5 to 0.600 ºC 15 -46 -46 +60
Refined Petro-
leum Products
Europe & Canada
API Table 54B
Density
kg/m3
653.0 to 1075.0 ºC 15 -50 -40 +95
Refined Petro-
leum Products
USA
API Table 6B API Gravity 0 to 85 ºF 60 -50 -40 +200
General API Table 54C Coefficient
0.000486 to
0.001674
ºC 15 -50 -40 +95
Lube Oil
Europe & Canada
API Table 54D
Density
kg/m3
800 to 1164 ºC 15 -50 -40 +95
Ammonia
Canada
NH3 N/A N/A ºC 15 -30 -30 +40
