7 Signet 2537 Flowmeter
Menu Details
This table shows the de¿ nition of each menu function, the setting parameters and the page where detailed instructions can be located.
Menu Function Defi nition Setting Parameters
More
Information
Flow Unit Liters or Gallons per sec, min., hour or day See list on page 8 page 8
K-Factor Set PULSES per VOLUME UNIT 0.0001 to 999999 page 8
Average Smooths out erratic À ow conditions 0 to 100 seconds page 9
Sensitivity Overrides Average for large rate changes 0 to 9 page 9
Mode Select the output mode Total or Divider or On-OFF page 10
P-Factor As PULSE DIVIDER, divides input freq. 1.0000 to 99999 page 10
P-Factor As PULSE TOTAL, multiplies K-Factor 1.0000 to 99999 page 10
Relay Logic Select Hi alarm or Lo alarm mode Hi or Lo page 11
Relay Set Set Relay Setpoint 0.0000 to 99999 page 11
Relay Hysteresis Rate inside Setpoint to DEENERGIZE relay 0.0000 to 99999 page 11
Relay Delay Time delay before relay is ENERGIZED 0000.0 to 6400.0 page 11
4 Set Set À ow RATE to be represented by 4 mA 0.0000 to 99999 page 8
20 Set Set À ow RATE to be represented by 20 mA 0.0000 to 99999 page 8
Contrast Adjust visibility of liquid crystal display 1 to 3 page 8
