43
Operatingandfunctions
8.6.10. configuring the transistor output Do1 to switch a load
when a warning message is emitted by the device
When the device generates a warning message, the device status LED is orange.
The generation of a warning message can also be indicated by the switching of the transistor output.
REtURN
On a version WITH relay out-
puts
On a version WITHOUT relay
outputs
OUtPUt
DO1
wARNiNG
DO2
iNV YEs
iNV NO
0......9
→
Choose the operating, inverted or not inverted, of the
transistor output.
DEL. 1= 00
→
Enter the time delay before switching value (value
between 0 and 99 s).
→
Confirm.
Fig. 39:
Configuration of the DO1 transistor output to indicate the generation of a warning message
8.6.11. configuring the Do2 and Do3 relay outputs
Any DO relay output can be configured either:
• to switch a load depending on two thresholds. See “Fig. 36”, chap. “8.6.7” and “Fig. 40”.
• to switch a load to indicate the fluid circulation changes. See “Fig. 41”.
• to switch a load when a warning message is generated by the device. See “Fig. 42”.
