Burkert Type 8045 - Manual (Page 14)

10
Description
5.4. Available versions
The following versions of the 8045 flowmeter are available.
These versions all have a 4-20mA current output (AO1) and a digital output (DO1).
relay
outputs
(Do2, Do3)
Digital input
(DI1)
material
of the
housing
Specification of the flow
sensor material of the
electrodes
order code
- - PC short, in PVDF Stainless steel 426498
long, in PVDF Stainless steel 426499
2 1 short, in PVDF Stainless steel 426506
long, in PVDF Stainless steel 426507
- - PPA short, in stainless steel Stainless steel 449670
long, in stainless steel Stainless steel 449672
2 1 short, in stainless steel Stainless steel 449671
long, in stainless steel Stainless steel 449673
- - PC short, in PVDF Alloy C22 558675
long, in PVDF Alloy C22 558676
- - PPA clamp, short, in stainless steel* Stainless steel 567797
2 1 PPA clamp, short, in stainless steel* Stainless steel 567798
*) Only with S020 for devices with a clamp connection.
English
Type 8045
