Burkert Type 8045 User Manual
Page 17

13
Technicaldata
H
T-fitting
Saddle
Spigot, in plastic
Welding tab with
radius, in stainless
steel
DN300
312
336
DN350
325
348
DN400
340
Fig. 3:
Dimension H in mm of the flowmeter 8045 with a G2" nut and inserted into an S020 fitting
88
88
116
189
153
180
91
21
Fig. 4:
Dimensions of flowmeter 8045 with a clamp connection [mm]
H
T fittings for measuring devices with a
clamp process connection
Welding socket for measuring devices with
a clamp connection
DN32
200
200
DN40
205
205
DN50
210
210
DN65
218
218
DN80
224
224
DN100
230
230
Fig. 5:
Dimension H in mm of the flowmeter 8045 with a clamp connection and inserted into an S020 fitting
English
Type 8045
