Installation
8.3.1. Specify the position of the plug-in
jumpers
ON (turned on)
OFF (turned off)
Fig. 19: Plug-in jumper K1 / K2
Fig. 20: Plug-in jumper K3 OFF
Fig. 21: Plug-in jumper K3 ON
Transducer Feedback
Plug-in
jumper K1
Plug-in
jumper K2
Plug-in
jumper K3
A
B
A
B
0 - 10 V
0 - 10 V
ON
OFF
ON
OFF
OFF
0 - 10 V
0 - 20 mA
ON
OFF OFF
ON
OFF
0 - 10 V
4 - 20 mA
ON
OFF OFF
ON
ON
0 - 20 mA
0 - 10 V
OFF
ON
ON
OFF
OFF
Transducer Feedback
Plug-in
jumper K1
Plug-in
jumper K2
Plug-in
jumper K3
A
B
A
B
0 - 20 mA
0 - 20 mA OFF
ON
OFF
ON
OFF
0 - 20 mA
4 - 20 mA OFF
ON
OFF
ON
ON
4 - 20 mA
0 - 10 V
OFF
ON
ON
OFF
OFF
4 - 20 mA
0 - 20 mA OFF
ON
OFF
ON
OFF
4 - 20 mA
4 - 20 mA OFF
ON
OFF
ON
ON
8.3.2. Parameterization steps
Specify direction of rotation of the shut-off valve
Normal direction of rotation (preset)
G
→
Press
the card (hold down push-button).
The GREEN LED lights up.
→
Release
connect the card from the power supply.
Reverse direction of rotation
R
→
Press
the card (hold down push-button).
The RED LED lights up.
→
Release
connect the card from the power supply.
