4.
INSTALLATION IN THE CONTROL CABINET
The distances to be observed for installation in the control cabinet can be found in the handbook for the SIMATIC
ET200iSP.
To facilitate replacement of an electronic module, the minimum distance indicated in the picture below is
recommended.
Distance to the control cabinet wall
60 mm
Fig. 7:
Distance to top of the control cabinet wall
Type 8650
