User Manual of iVMS-4000(V2.03)
Chapter 11 E-Map
Click key to show the e-map window.
Toolbar Buttons Descriptions:
Buttons Descriptions Buttons Descriptions
Enable/Disable Map Edit Enter/Exit Full Screen
Zoom Out Previous Page
Zoom In Next Page
Zoom Adjustment Upper Level
11.1 Add Map
1 st step: Click button to enter map edit mode, the cursor will become as
2 nd step: Right click the black area and select “Add Map” (or click button to display Map Info Area and
right click the area and select “Add Map”), then the Add Map window will pop up.
98
