User Manual of iVMS-4000(V2.03)
Play Control Buttons Time Axis Area
8.1.1 Remote VOD Query
1 st step: Select the window for playback and the channel
from the site tree.
For the channel which has been configured with NVR
recording, there will be available with two options under the
channel name in the site tree: Device Disk and NVR.
2
nd step: Select recorded file type and query time. If user has selected NVR from the channel, then only the
Schedule and Motion Detection record file types are available.
3 rd step: Add information of card number. For ATM DVR, user can enable “Query by Card No.” and input the
overlaid card number to search. Other device can skip this step.
4 th step: Click the button to search the matched recorded files. If there is record files
existed, then it will be displayed in the time bar area.
5 th step: Click the button to start playback. You can choose time by dragging mouse to the desired
position on the time bar.
51
