eLine Technology iVMS-4000 V2.03 - Manual (Page 60)

User Manual of iVMS-4000(V2.03)
Area Description Area Description
Device list Time line
Search options Log info
Note: Event playback function is supported by DS-9000/9100 series DVR, with firmware version 1.1 or
higher.
8.3.1 Record Search
1 st step: select a device.
2 nd step: select the event type to motion detection or sensor alarm, and then select the channel/alarm input
number, as well as the event date.
3 rd step: click to search record file, if there are record file match the options, they will
be display on the time line.
4 th step: select the channels needed to be playback, move the mouse and select a time point, then
click , selected channels will playback record synchronously.
Note: Up to 4 channels can be handled for synchronous event playback.
59
